Architect-2660 (Discontinued)
- VendorAudioControl
Architect-2660 (Discontinued)
- VendorAudioControl
| Inputs | |
| Inputs | 8 Stereo Local Analog Inputs, 1 Stereo Bus Coaxial Digital Input, 1 Stereo Bus Analog Input |
| Input Sensitivity | Variable 0 to 1 Vrms Analog: 1 Vrms for full output; level at maximum |
| Control | |
| 12 V Trigger | +12 VDC or Dry Contact Closure |
| Outputs | |
| Amplifier Channels | 16 |
| Power Output (8 Ω) | 65 W per channel |
| Power Output (4 Ω) | 100 W per channel |
| Power Output (Bridged) | 175 W |
| Minimum Loudspeaker Load | 4 Ω |
| General | |
| Power Consumption | Standby: 0.4 W Idle: 30 W Loud listening level: 217 W Maximum: 1300 W |
| BTU/Hour Heat Dissipation (Standby) | 1.4 BTU/hr |
| BTU/Hour Output (Idle) | 92 BTU/hr |
| BTU/Hour Heat Dissipation (loud listening level) | 1/8th power: 297 BTU/hr |
| BTU/Hour Heat Dissipation (maximum) | 890 BTU/hr |
| In the Box | Architect Model 2660, Loudspeaker Connectors, Remote Connector, Power Cord, Manual, Warranty |
| Power | |
| Protection | clipping, short circuit, thermal, ultrasonic, DC offset, stable into reactive or mismatched loads |
| Performance | |
| Damping Factor | >200 |
| Signal-to-Noise Ratio | >105 dB, (A-wtd, ref full output) |
| Crosstalk | >80 dB @ 1 kHz |
| Gain | 27 dB |
| DAC Specifications | 32 to 192 kHz sample rate, 16-/24-bit depth |
| Physical | |
| Dimensions (Unit) | W × D × H: 17 × 15.5 × 3.5 in (2 RU) |
| Weight (Unit) | 16.0 lb. (7.3 kg) |
