Director D4600
- VendorAudioControl
Director D4600
- VendorAudioControl
The Director® D Series feature on-board digital signal processing, graphic & parametric equalization by zone, network monitoring and programming, local and bus inputs, plus the addition of volume control, channel/zone grouping and zone audio presets. They also allow individual channel and zone selection via standard TCP/IP, delivering incredible power and AudioControl’s legendary audio performance.
![]() | ![]()
| ![]() |
AudioControl features a collection of over a thousand speaker profiles, crafted for a variety of vendors using publicly available information, enabling tailored profiles to be created and stored in software form.
Speaker profiles provide the custom integrator with tools to deliver a premium entertainment experience by fine-tuning systems for their clients.
| Inputs | |
| Inputs | 8 Analog Stereo Local Inputs, 2 Analog Stereo Bus Inputs |
| Input Sensitivity | 1 Vrms for full output, level at maximum |
| Gain | 30 dB |
| Control | |
| 12 V Trigger | +12 VDC or Dry Contact Closure |
| Network / IP Control | 10Base-T Ethernet TCP/IP |
| Communication Protocol | HTTP or Telnet |
| Outputs | |
| Amplifier Channels | 16 |
| Power Output (8 Ω) | 100 W per channel |
| Power Output (4 Ω) | 200 W per channel |
| Power Output (Bridged) | 8 Ω: 400 W |
| Minimum Loudspeaker Load | 4 Ω |
| Preamp Outputs | 8 Stereo Local Loop Outputs, 1 Stereo Bus Loop Output |
| Physical | |
| Dimensions (Unit) | W × D × H: 17 × 15.5 × 3.5 in (2 RU) |
| Weight (Unit) | 19.2 lb. (8.7 kg) |
| Performance | |
| Signal-to-Noise Ratio | >95 dB, A-wtd, ref full output |
| Crosstalk | > 80 dB @ 1 kHz |
| Damping Factor | >300 |
| General | |
| In the Box | The Director Model D4600, Loudspeaker Connectors, Remote Connector, Power Cord, Manual, Warranty |
