Allows easy connection of up to four emitters to a single IR port.
Compatible with most industry standard single or dual IR emitters.
Sturdy steel construction.
A power supply is not required for the IPE-4 to function.
A 3' (1m) molded mono-cable with 3.5mm mini-plugs is included for easy connection to RTI processors.
| General | |
| Infrared Input Port | 3.5 mm jack Compatible with RTI control processors and industry standard repeaters/receivers |
| Number of Output Ports | Four |
| IR Output Ports | 3.5 mm jacks; Works with industry standard IR emitters |
| IR Output Drive | 100 mA maximum (per port) |
| Mounting | Wall-mount or free standing |
| Dimensions (Unit) | W × D × H: 130 × 23 × 48 mm (5.1 × 0.9 × 1.9 in.) |
| Operating Temperature | 32 to 122 °F (0 to 50 °C) |
| Operating Humidity | 5% to 95% RH, non-condensing |
| Weight (Unit) | 6.8 oz. (192 g) |
| Warranty | 3 years (parts & labor) |
| Prop 65 | WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
Included in the box:
- IPE-4, ,
- Cable (3ft)
- Screws & drywall anchors (4)
- Operation guide
