10 Pack of AC-EX70-UHD-ARC-KIT HDMI Extenders
- VendorAVPro Edge
Extend 4K HDMI: The manufactured HDMI cable length is unchangeable and unreliable after about 25FT. Additionally, HDMI connectors can only be terminated in a specialized factory environment due to their high frequencies and density. This does not allow installers or users to remake or make cables on a DIY basis. CAT-6A cables are widely available and can be reworked easily by the installer or end-user.
Audio Return Channel: ARC allows you to deliver local audio from internal smart tv apps like Netflix, Hulu, or Disney+ back to your headend. You can then distribute this audio through amplifiers for enhanced audio experiences. Audio return channel is not available through the tos out or L/R out ports on the transmitter, only through the HDMI port.
Distance: By using AC-EX70-UHD-ARC, the transmission distance for HD 1080P is up to 70 meters (230’), and UHD 4K resolution reaches an impressive 40 meters (115’).
Control: IR & RS-232 are bi-directional and can control the sources from the sinks or vice versa.
Bi-Directional Power: The PoH (Power over HDBaseT) function is intended to power Rx from the Tx or Tx from the Rx. The advantage of a lightweight (160 gram) super-slim extender is it can be mounted anywhere where space is premium.
Field Updates: Should a firmware update be necessary, it can be accomplished in the field
Total EDID Management: The AC-EX70-UHD-ARC has robust EDID control. EDID management allows you to manage the input device and request specific video resolutions and/or audio codecs. The following EDID options are available:
The EDID Copy Function allows you to copy and save from any display or projector you want to.
I-Pass: Plug your Control System emitter ports directly into the IR port on the transmitter (via mono 3.5mm cable) for clean and reliable IR pass-through. Our unique VPC (Voltage Protection Circuit) allows you to do this without wear and tear on the sensitive electronics inside.
| Video | |
| Video Resolution | Up to 4K 60 Hz 4:2:0 & 4K30 4:4:4 |
| VESA Resolutions | Up to DCI 4K (4096x2160) |
| Color Space | YUV (Component), RGB (CSC: Rec. 601, Rec. 709, BT2020, DCI, P3 D6500) |
| Chroma Subsampling | 4:4:4, 4:2:2, 4:2:0 |
| Color Bit Depth | Up to 16-bit (1080p), up to 12-bit (4K) |
| Audio | |
| Audio Formats Supported HDMI | PCM 2.0-Ch., LPCM 5.1 & 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS:X, Dolby Atmos |
| ARC Support | Yes |
| Distance | |
| HDBaseT Distance (4K) | 60 4:2:0: 40 m (131 ft.) (CAT 6A) |
| HDBaseT Distance (1080p) | 70 m (230 ft.) (CAT 6A) |
| HDMI Cable Distance (Passive) | Up to 50 ft. (using Bullet Train HDMI) |
| HDMI Cable Distance (AOC) | Up to 130 ft. (using Bullet Train AOC) |
| Other | |
| Bandwidth | 10.2 Gbps |
| CEC | Yes |
| HDCP / Copy Protection | HDCP 2.3 and earlier |
| Ports | |
| HDMI | Type-A |
| HDBaseT | RJ45 w/ PoH for HDBaseT Receivers |
| IR | 3.5 mm |
| Audio INPUT/OUTPUT (RX/TX) | 3.5 mm Stereo / mini-TOSLINK |
| RS-232 | 3 Pin Terminal Block |
| Power | TX & RX: 2 pin terminal block |
| Environmental | |
| Operating Temperature | 23 to 125 °F (-5 to 51 °C) |
| Storage Temperature | -4 to 140 °F (-20 to 60 °C) |
| Operating Humidity | 5% to 90% RH, non-condensing |
| Power | |
| Power Consumption | Total: 12 W max |
| Power Supply | Matrix: Input: AC 100 V to 240 V ~ 50/60 Hz Output: DC 48 V 0.5 A |
| Physical | |
| Dimensions (Unit) | W × D × H: 122 × 75.2 × 11.7 mm (4.8 × 2.96 × 0.46 in.) |
| Dimensions (Packaged) | W × D × H: 155 × 133 × 86 mm (6.1 × 5.3 × 3.4 in.) |
| Weight (Unit) | 0.2 lb. (0.09 kg) |
| Weight (Packaged) | 1.6 lb. (0.73 kg) |
| Notes | *Specifications subject to change without notice. Mass & dimensions are approximate |
