TAA - MXnet 1G Control Box
- VendorAVPro Edge

TAA - MXnet 1G Control Box
- VendorAVPro Edge

Time Saver - Setup and configure your new AV/IP project in record time.
Frustration Saver - Troubleshooting has never been easier. MXnet Mentor’s diagnostics are live, providing immediate feedback as to the condition of your HDMI cable connections, network cable connections, resolution, and much more.
Free Your Creative Side - MXnet Mentor helps you to easily setup and create unlimited video walls with unique styles and asymmetrical arrays.
Powerful Control Options - Easily setup power control interdependencies either using encapsulated RS-232 over IP commands or CEC over HDMI power controls. Additionally, Mentor supports RS-232 and IR direct routing for setting up 3rd party control processing.

Netgear Support - MXnet’s engineers have worked together with Netgear to ensure their switches work with our line of encoders and decoders. To make installing MXnet with Netgear switches even easier, Netgear has developed an “AVPro Edge Profile.” Once this is loaded, your switch will work seamlessly with the AVPro Edge encoder and decoders.
For more information, please visit this website - https://www.netgear.com/business/solutions/av-over-ip/
| Ports | |
| Ethernet / LAN | (8) × female RJ45, one with PoE |
| SFP / SFP+ | 0 |
| HDMI | N/A |
| Audio | N/A |
| IR | N/A |
| RS-232 | (1) × 5 Pin Terminal Block for MXnet System Control |
| USB | (1) × USB Micro Type-B for MXnet service |
| Distance | |
| Ethernet / LAN | 100 m (330 ft.) over CAT 5e and above |
| SFP / SFP+ and Fiber | N/A |
| Environmental | |
| Operating Temperature | 23 to 125 °F (-5 to 51 °C) |
| Storage Temperature | -4 to 140 °F (-20 to 60 °C) |
| Operating Humidity | 5% to 90% RH, non-condensing |
| Power | |
| Power Consumption | Max: 4.5 W |
| PoE | IEEE 802.3af (15.4 W) |
| Power Supply | Input: AC 120 V to 240 V-50/60 Hz 0.8 A Output: DC 12 V 2 A |
| Physical | |
| Mounting | Rack and Furniture mount support |
| Dimensions (Unit) | W × D × H: 200 × 104 × 20 mm (7.87 × 4.09 × 0.79 in.) |
| Dimensions (Packaged) | W × D × H: 310 × 180 × 54 mm (12.2 × 7.09 × 2.13 in.) |
| Weight (Unit) | 1.26 lb. (0.57 kg) |
| Weight (Packaged) | 1.74 lb. (0.79 kg) |
| Regulatory / Certifications | FCC, CE, UL |
| Warranty | 10 years; Specifications subject to change without notice. Mass & dimensions are approximate |
| *4K60 4 | 4:4/4K60 4:2:2 Uses ICT Compression |
