Fast Switching – Enjoy almost instant source to source switching to any receiving endpoint. On average, MXnet switches the same timing and resolution sources in less than 2 seconds with zero black frames.

Low Latency – The average latency time between audio and video onset is around 35ms. Anything 40ms or less is invisible to human eyes and ears. We tested thoroughly and found that different signal types can play a role in latency, so we have our findings listed here:


• MXnet Point to Point (HDMI or Decoder Analog Out)
  • Less than or equal to 33MS (1Frame)
• MXnet Encoder (Non-Downmixing/2CH PCM Only)
  • Less than or equal to 1MS
• MXnet Encoder (AVDM)
  • Less than or equal to 60MS
  • 60MS achieved only when downmixing HBR audio (Dolby TrueHD or DTS Master Audio), usually less. It should be noted that anything less than 100MS is considered unnoticeable.

IAVP ( Intelligent A/V Processing ) – We re-engineered and optimized every system module that impacts multicast processing.  That includes a complete reworking of IGMP, Jumbo Frames, Spanning Tree, and multicast filtering.

MXnet NOS (Network Operating System) – Multicast CPU utilization has been completely reworked, resulting in amazing efficiencies.  Processor loads will never exceed 40% even when the switch is fully populated. System boot times take 1 min 45 sec from a cold power up to full functionality, including POE device power-up.
